In qualità di produttore e fornitore specializzato divalvole a sferain Cina,Huitongha sviluppato la valvola a sfera in ottone per caldaie specificatamente per condizioni di circolazione della caldaia ad alta temperatura. Presenta una maggiore resistenza al calore e alla pressione, che lo rende adatto al controllo del flusso d'acqua nelle caldaie murali e nelle piccole caldaie industriali.
1. The valve is forged from high-density HPb59 brass as a single unit, ensuring structural stability in high-temperature environments and preventing material embrittlement during prolonged exposure to hot water.
2. The thickened valve body design accommodates the fluctuating water pressures found in boiler systems, withstands water hammer shocks during start-up and shutdown, and minimizes the risk of leakage or cracking.
3. A surface passivation treatment reduces scale buildup from high-temperature water, slows oxidation and corrosion caused by continuous thermal cycling, and extends the valve's service life.
1. It utilizes a high-temperature-resistant modified PTFE seat that withstands continuous exposure to circulating hot water; the material resists hardening and shrinkage, ensuring a consistently tight seal.
2. The valve stem is wrapped in multi-layer composite heat-resistant packing to prevent minor leakage at the stem area caused by thermal cycling.
3. The chrome-plated solid ball core offers excellent wear resistance; repeated opening and closing will not cause scratches, thereby preventing leakage paths from forming at the sealing interface.
1. The optimized, compact valve body fits into limited installation spaces, such as the cramped areas beneath wall-hung boilers or within equipment service voids.
2. The valve features standard universal threaded connections, allowing for direct attachment to wall-hung boiler inlets/outlets and pipeline heat exchangers, thereby reducing the need for adapter fittings.
3. An optional extended operating handle prevents burns from hot piping, ensuring safer operation for maintenance personnel.
1. Water inlets and outlets for residential gas wall-hung boilers, controlling flow for space heating and domestic hot water lines.
2. Branch line control for circulation piping in small commercial hot water boilers and heat exchange units. 3. Control of media shut-off for boiler-associated expansion tanks, make-up water lines, and blowdown piping.
1. The structural pressure-bearing specifications are optimized for high-temperature water hammer conditions, exceeding the design requirements for standard ambient-temperature ball valves.
2. The complete sealing assembly has undergone high-temperature durability testing; standard sealing components designed for ambient-temperature piping are unsuitable.
3. It offers superior resistance to thermal cycling, accommodating the rapid temperature fluctuations caused by the intermittent start-stop operation of boilers.
1. In addition to standard inspections, raw materials undergo supplementary thermal cycling simulation tests to select blanks suitable for high-temperature conditions.
2. Random inspections of finished products include high-temperature pressure-retention tests to verify sealing stability under conditions simulating long-term boiler operation.
3. Individual records are established for each product batch, with material reports and test records fully archived to ensure quality traceability.
